Détail: | 24x 10/100/1000 PoE+ ports with 375W power budget, 4x Gigabit SFP, Rack-mountable |
Modèle: | C1200-24FP-4G |
État: | Usine scellée nouveau |
En relation: | |
Garantie: |
![]() ![]() ![]() |
Livraison: |
Transport aérien à
États-Unis d’amérique
,La plupart des clients reçoivent pendant 5-7 jours
?
Si vous finissez le paiement aujourd’hui,
Votre commande arrivera dans le Délai de livraison estimé. |
Expédié à:
5
|
2 à 7 jours
US$
|
Paiement: |
Plus de détails
|
(Note: Cisco discount and stock always changed, we will try most effort to follow it but can not ensure every web price was changed in time. So Our Products Service will contact you after order if meet such special condition.)
The Cisco C1200-24FP-4G is a powerful switching solution designed for modern networks. Featuring 24x 10/100/1000 PoE+ ports, this switch combines performance, scalability, and security to meet a variety of business needs. With PoE+ capabilities, it ensures that your network devices are powered effectively, making it an ideal choice for businesses looking to streamline their network architecture.
Code du produit | C1200-24FP-4G |
Les Ports | 24x 10/100/1000 PoE+ |
Liens ascendants | 4x Gigabit |
Puissance sur Ethernet | PoE+ |
accessoire | modèle |
Cisco Wireless Access Point | AP3802I-B-K9 |
Rack Mount Kit | RM-PA-T6-2 |
Cisco SFP Module | GLC-SX-MMD |
modèle | Differences |
Cisco C1200-24P-4X | 24x 10/100/1000 Ports, no PoE |
Cisco C1200-48FP-4G | 48x 10/100/1000 PoE+ Ports |
Cisco C1000-24P-4G-L | No PoE+ support, limited stacking options |
Do you have any questions about the C1200-24FP-4G?
Contactez-nous maintenant via [email protected]
Nom du produit | C1200-24FP-4G |
Capacité en millions de paquets par seconde (MPPS) (paquets de 64 bytes) | 41,66 m € |
Capacité de commutation en gigabits par seconde (Gbps) | 56,0 et 56,0 |
Power dedicated to PoE | 375W |
Number of ports that support PoE | 24 |
Consommation d’énergie du système | 110V=28.9W 220V=29.8W |
Power consumption (with PoE) | 110V=443.5W 220V=429.9W |
Heat dissipation (BTU/hr) | 1512.3 |
Idle Power | 110V=16.5W 220V=17.4W |
Total des ports du système | 28x Gigabit Ethernet |
Ports RJ-45 | 24x Gigabit Ethernet |
Combo ports (RJ-45 + Small Form-Factor Pluggable [SFP]) | 2x SFP |
Packet buffer | 1,5 mo |
Unit dimensions | 445 x 345 x 44 mm (17,5 x 13,59 x 1,73 po) |
Unit weight | 4.6 kg (10.14 lb) |
Fan (number) | 1 |
Bruit acoustique | 25°C: 34.8 dBA |
MTBF at 25°C (hours) | 698,220 |
Ce qui est garanti.
Après avoir reçu votre commande, prenez un mois complet pour l’essayer. Si vous trouvez que la qualité n’est pas bonne, nous#39; vous le reprendrez et vous rembourserez votre argent. Votre entière satisfaction est garantie ou votre argent remis. Que et#39; S garanti.
Après vos articles de commande qui sont disponibles. Nous utiliserons la plupart de manière rapide de la livraison aux pays globaux. Normalement nous embarquerons des cargaisons pendant 3 -5 jours. Et la livraison internationale prendra environ 3- 10 jours selon votre emplacement.
Le Service ne s’arrête jamais.
Matériel Warrany temps:
Nouveau matériel Original scellé: 3 ans
Appareils originaux remis à neuf/usagés: 1 an
Après le temps de garantie, vous pouvez également nous contacter pour retourner de nouveau pour le service de réparation. Tout ce que vous achetez sur HI-NETWORK.COM. Nous offrirons l’appui en ligne de vie de service pour vos n’importe quelles questions possibles.
